Motor for Fenner SPX Snow Plow Pump 2 Posts 9 Spline
Motor for Air Flo Quick Silver Snow Plow
Replaces part #
Air Flo 15056,
Fenner 1472AC, 1788, 1788AC, 1790AC, 2578AC
Fenner, 1472AC
Fenner SPX Stone, 1788
Fenner, 1788AC
Fenner, 1790 AC Fenner, 2578AC Fenner
Air-Flo Replacement Snow Plow Hydraulic Pump Unit Motor//12V//CW//9 Spline
Applications: Air-Flo Quick-Silver, Fenner, Stone, SPX Hydraulics
Part #: 51022
Voltage: 12.00
Rotation: CW
Overall Length: 7.250 in.
Shaft Outside Diameter: .480 in.
Shaft Style: 9 Spline
Terminal 1 Size: 5/16 - 24
Terminal 2 Size: 5/16 - 24
Housing Finish: Field case is plated yellow zinc.
Weight: 19.7 lbs.
Cross References:
Air Flo: 15056
Fenner/Fenner Stone/SPX: 1472AC, 1788, 1788AC, 1790AC, 2578AC
Iskra: 11-212-385
Lester: 10739, 160-868
Replaces Part #
Air Flo: 15056
Fenner/Fenner Stone/SPX: 1472AC, 1788, 1788AC, 1790AC, 2578AC
Iskra: 11-212-385
Lester: 10739, 160-868
This Aftermarket motor will replace the following OEM #;s
Air Flo: 15056
Fenner/Fenner Stone/SPX: 1472AC, 1788, 1788AC, 1790AC, 2578AC
Iskra: 11-212-385
Lester: 10739, 160-868
http://air-flo.com/dl/Snow%20Plow%20manual_lo%20res1.pdf
Manual for Air Flo Quick Silver Snow Plow showing this is the correct motor
